BSM-70 Scrap Motor Pulling Machine

Copper Winding Puller machine for recycling scrap electric motors

BSM-70 scrap motor pulling machine was designed to recycle copper windings from scrap electric motors after motor case was removed, this machine has a simple and elegant appearance, rugged industrial construction, ergonomic working height, compact size, and easy operation. It only have the pulling parts for standard configurations, you also can choose to assemble different optional parts, such as: cutting part.

A Professional Scrap Metal Recycling Machine Manufacturer in the Market

BSM-70 Scrap Motor Recycling Machine

· 1 Pulling part and combinative design based on your scrap motors, suitable for small stator recycle.

· Optional:

+ You can add a cutting part to your BSM-70 scrap motor pulling machine, which can help you cut one end of the copper winding, making the machine more convenient to use, saving time and effort.

+ Support Customized Voltage and Color

BSM-70 is suitable for small motor stators with a diameter range of 40-200mm. If you need to process motor stators with a diameter bigger than 200mm, you are welcome to choose our:

+ BSM-50 Electric Motor Cutting Machine

+ BSM-40 Multifunctional Motor Recycling Machine

can process motor diameter below 500MM.

The Recycling Effect of the copper winding puller Machine

BSM-70 copper winding puller is only has the pulling function, it pulls out the stator steel through jaws and pulling platform coordinate to work together. There are many kinds of motors in the market, and they can all be processed by our motor cutting machine and our motor pulling recycling machine. Through the actual processing video, it’s easy to find the final product is complete which has high economic value.

technical data:

Model	BSM-70 Scrap Motor Pulling Machine
Motor Stator Outer Diameter(MM)	40-200
Motor Power	3KW
Capacity	200-300PCS/H
Dimension(MM)	L1500W650H800
Weight	430KG
Delivery	LCL

The Structure of BSM-70 Motor Recycling Machine

From the picture below you can see the detailed constitution of BSM-70 scrap motor recycling machine added with a cutting part, with this configuration, customer also can cutting motor stators more convenient in one machine, save space and cost.

1. Pulling Part

2. Grasping Part

3. Isolation Baffle

4. Grasping Handle

5. Pulling Handle

6. Motor

7. Oil Tank

8. Pedal

9. Cutting Part(Optional)

Grasping Claws

Pulling Hydraulic cylinder

The Main Structure of the machine can be divided into Grasping part and Pulling part.

Grasping part: There are two rows of fang-shaped claws having very strong force and also made of hard material thus can grasp the copper winding tightly.

Pulling part: The claws on the left and right side come together and catch the copper windings, the pulling platform above them will also come together and catch the motor silicon steel, after the grasping action is completed, the pulling platform will rise, then the copper winding and stator will be separated.

Note: As we mentioned above, the machine can be integrated with our other waste electric motor stator cutters, which means if you you have larger quantities and sizes of waste electric motors to process, you can also add a cutting part or select our BSM-50 Electric Motor Cutting Machine.

Attentions Before Processing

1. Check the electrical box of the machinery, ensuring it is not exposed to moisture.

2. Check that there are no flammable materials around to avoid dangerous accidents.

3. Inspect oil pipelines for leaks or press to tight to ensure safe use and machine bolts are fasten.

4. Inspect the pulling copper parts: there are two running tracks under that require lubrication. It is better to apply lubricating oil at least twice per day.

5. It is imperative to prioritize safety during operations. Appropriate operators should be assigned, and they should wear suitable work uniform before operations.

BSM-70 Copper Winding Puller Machine Features:

BSM-70 copper winding puller has a small size and compact structure. It can be flexibly assembled with cutting parts and is easy to relocate.
The machine is easy to operate and only requires one operator to complete the operation.
Rugged industrial construction: Our machines are made of national standard quality materials and have a solid structure, which can ensure your long-term use without being easily damaged.
Ergonomic working height: We design the machines at an ergonomic height to make it easier for workers to operate them.
Torque capability: The BSM-70 has a strong torque capability. It can easily pull out the copper windings in scrap motors.

Possbile problems and solutions

Insufficient hydraulic oil. When the hydraulic cylinder fails to operate smoothly (or doesn’t operate at all), please check first if there is enough hydraulic oil.
Electromagnetic valve blockage. If the hydraulic cylinder fails to operate normally (or lacks pressure), please use a slender object with a diameter less than 4 millimeters to repeatedly poke and press the metal dots at both ends of the electromagnetic valve while the machine is stopped. Only after manually ensuring the hydraulic circuit is clear can normal operation resume.
Lack of lubrication in the top knife rail can cause the top knife to operate unevenly. Please remember to lubricate it promptly and regularly.
Lack of lubrication in the copper pulling jaws rail can cause operate unevenly. Please remember to lubricate it promptly and regularly.
After long time operation, the core part of the copper-grabbing machine head may naturally come loose. To fix this, you need to remove the 6 screws at the back end of the cylinder connecting to the oil cylinder, twist the core to the deepest part of the oil cylinder push rod, tighten the locking screws, and then reconnect the cylinder and the oil cylinder.
When only one function is used for an long period of time without use other functions, after each startup, it’s necessary to start every function before proceeding with normal operation. Otherwise, the function that is not used for a long time will change, and affect the operation of the whole machine.
