BS-4 Copper Wire Stripper Machine

Multifunction, one machine can deal with a wide diameter range from 2-80mm for different wire types.
Small and compact size could be moved easily.
Cost-effective feature helps you save money.
Good quality allows you use it continuously to reach high efficiency.

product details

The BS-4 copper wire stripper is a combination of BS-009 and BS-3. The left part is the BS-009 and the right part is the BS-3. The left side handles cables with a diameter of 1-40mm including square cables and sheathed cables. The right side processes cables with diameters bigger than 40mm. BS-4 expands the scope of processing capacity and better meets customer needs.

Video Description

The video is about the BS-4 copper wire stripper machine:

Customer in China
Range： 2-80MM
Power: 2.2KW
Weight: 121kg
Machine Size: 850*440*570mm

It is the popular machine for sure. You will learn how it works through the video and the man in it is a Chinese customer who is satisfied with our product. It is suitable for diameter range form 2-80mm. If you have corresponding needs, you can choose a BS-4 copper wire peeling device for your copper recycling business. Of course we have other kinds of copper recycling machine, such as wire granulator machine. We welcome your inquiries at any time.

Leading Copper Wire stripper machine manufacturer

Model	BS-4 Copper Wire Stripper Machine
Applicable Scope	2mm-80mm
Size	850440570mm
Weight	121kg
Power	2.2kw

Structure of BS 4 Copper Wire Stripper

A.2 cores flat cables/wires feeding slots
B.Diameter 2-5mm cables/wires feeding slot
C.Diameter 5-10mm cables/wires feeding slot
D.Diameter 10-15mm cables/wires feeding slot
E.Diameter 15-20mm cables/wires feeding slot
F.Diameter20-25mm cables/wires feeding slot
G.Diameter 25-30mm cables/wires feeding slot
H.Diameter 30-40mm cables/wires feeding slot

BS-4 copper wire stripping machine has 9 holes on the left with 13 blades and can strip 2-40mm wire diameter. There is a wire entry on the right with 2 blades but the stripping diameter range can reach 2-80mm. You need to adjust the handle to process different sizes of wires.

working process of BS 4 Copper Wire Stripper
